Welding Wire Straight Type Draw Bench Drawing Wire Machines

Welding Wire Straight Type Draw Bench Drawing Wire Machines

Overview Welding Wire Straight Type Draw Bench Drawing Wire Machines Production process : High carbon steel wire coil---
SHARE

Description

Basic Info
Wire Material High Carbon Steel Wire ,1065, 1070
Capstan Diameter 560 mm
Drawing Speed 8-12 M/Min
Transport Package Plastic Packaging
Trademark LAIJI
Origin Anping County, Hebei Province, China
HS Code 8463300000
Production Capacity 10 Sets/Month
Product Description
Welding Wire Straight Type Draw Bench Drawing Wire Machines
Production process :
High carbon steel wire coil---Mechanical derusting---Belt polishing machine---Boron coating drying treatment---straight line wire drawing machine---Trunk take-up machine


This machine is equipped with jumper device, which can cut off the drum and draw at will to adapt to different processes. It is suitable for drawing a lot of materials, such as prestressed steel wire, tire steel wire, rubber hose steel wire, spring steel wire, steel cord and other metal wires.

Different from the ordinary wire drawing machine, the direct feed wire drawing machine adopts AC frequency conversion control technology or DC programmable control system and screen display,
with high degree of automation, convenient operation and high quality of drawn products. It is suitable for drawing various metal wires with diameter less than 12 mm.

Product Parameters

ModelUnitLZ400LZ560LZ600LZ800
Capstan diametermm400560600800
Drawing diesTimes9999
Inlet wire diametermmΦ2.5-4.5Φ5.5-6.5Φ6.5-8.0Φ8.0-10
Outlet wire diametermmΦ0.8-1.4Φ1.6-2.0Φ2.0-3.0Φ2.8-3.5
Drawing speedm/s10-168-126-126-10
Total reduction rate%90.3290.5390.5390.53
Motor powerKw11-1530-3730-3737-75
